Grease Filters Commercial Kitchens

Grease filters commercial kitchens is designed to collect grease and stop flames from penetrating into hood exhaust ductwork. They can be made of stainless steel, galvanized, and aluminum material with electrolytic polishing or anodic oxidation finish. This filter contains two layers of equally spaced roll or square formed baffles which creates airflow to collect efficiently grease and make grease into the collecting trough finally. Its frame shall be formed metal channel, and each frame is connected with heavy rivets. The grease filters commercial kitchens offers a strong, tough, rugged surface and it costs low.

  • SBF-501
  • 8421999000
  • Ningbo, China
  • 50000PCS/Year
  • T/T, Western Union
  • by Carton or by Pallet
  • SBF-501
  • 490(a)*490(B)*50mm
  • no
  • by Carton
  • Zhejiang
  • 8421999000
  • Metal
  • Single
  • Grease Filter
  • Perforated Metal Mesh
  • Line
  • Double Layers

Product Description

At Shionp you never have to worry about low-quality vent hood filters or compliance issues commonly found with low-grade filters. Our grease filters commercial kitchens are some of the most durable on the market. Nearly all of the filters at Shionp are UL listed and meet NFPA requirements. Our selection of restaurant baffle grease filters includes galvanized aluminum or stainless steel baffle filters. Choosing the right hood filter material generally depends on the visibility of your kitchen as well as the types of appliances you will be using the filter with.


The grease filters commercial kitchens, particularly grease baffle filters, work by catching grease before it goes up into your kitchen hood system. You need filters that are in good working condition, without missing or banged up parts, to keep your restaurant compliant with fire codes. It is also a fire hazard to have filters with grease build upon them, which means they need to be cleaned or changed frequently. Cleaning them, however, can be a difficult and complicated process. Not only does washing them improperly wastewater and other resources, but cleaning them in a sink risks ruining your equipment with the grease running into your plumbing, sticking to pipes, and damaging other items you are trying to keep clean.



Description of Commercial Kitchen Extractor Filters:

Size:490(A)*490(B)*50mm

Material:AISI 430/201/304 stainless steel

Features of Commercial Kitchen Extractor Filters:

Structure: double layers, stainless steel groove.

Application: Used for kitchen and filtration system

Advantage : Large oil holding capacity, high temperature resistance ,durable

Details of Commercial Kitchen Extractor Filters:
Rigid structure with double welding
Dishwasher washable
Standard sizes designed to fit most kitchen hoods
Filtering capacity:1.8m3/sec.(ref.501&503)

Other sizes and materials available on request
